Hafele

Corner Bench Hinge

$31.31

Effortless comfort meets precision engineering — designed to lift your seating experience to new heights.

The Corner Bench Hinge is crafted for seamless functionality and safety, transforming any corner seating into an inviting space with easy access. Made from robust steel with a protective blue galvanised finish, this hinge is engineered to support seat panels up to 12 kg with grace and reliability. Its expertly designed opening stop prevents the seat panel from hitting the fitting, ensuring smooth, damage-free operation every time.

With a generous swivel range to the front, this hinge allows seat panels to lift even when thickly padded, making it ideal for cozy benches or storage seating. The clever spring mechanism balances the panel’s weight, making opening effortless and secure without the need for additional hinge connections. This hinge offers a refined blend of durability, comfort, and design to enhance any seating solution.

Features

Safe, reliable lift-up hinge for corner bench seat panels
Large swivel range for easy front lift, accommodating thick padding
Opening stop prevents damage by limiting seat panel movement
Integrated springs provide optimal weight compensation for up to 12 kg panels
Blue galvanised steel finish for lasting durability

Specifications

Material: Steel
Finish: Blue galvanised
Opening Angle: 95 degrees
Suitable Panel Weight: Up to 12 kg
Installation: No separate hinge connection required; designed for smooth joint integration
Area of Application: Corner bench seat panels with lift-up function


Price
$31.31
