Hettich Intermat 95° Thick Door Hinge — Full Overlay
A precision-engineered concealed hinge built to handle the demands of thick cabinet doors without compromise.
Constructed from nickel-plated steel, the Intermat 95° delivers a refined, corrosion-resistant finish suited to high-use cabinetry environments. Its full overlay configuration ensures the door face sits flush over the cabinet side panel, maintaining clean sightlines. The press-in installation mechanism — with pre-mounted expanding dowels — eliminates the need for screws at the cup, making it a practical choice for production and trade applications alike.
Product Details
- Material: Steel, nickel-plated
- Opening angle: 95°
- Door thickness: 14–32 mm
- Overlay: Full overlay (B 12.5)
- Cup depth: 10.5 mm
- Drilling pattern (TH): 52 × 5.5 mm
- Installation: Press-in with pre-mounted expanding dowels
- Integrated overlay adjustment: +2 mm / −2 mm
- Integrated depth adjustment: +2.5 mm / −1.5 mm
- Height adjustment at mounting plate
- Self-closing feature included (Intermat 9936)
- Quality classification: EN 15570, Level 2
Best For
Suited to kitchen, wardrobe, and furniture cabinetry where door panels exceed standard thickness — particularly 18–32 mm slab or frame doors. The press-in format suits high-volume joinery and flat-pack assembly where installation speed matters. Engineered in Germany to EN 15570 Level 2, it meets the load and cycle requirements of residential and light commercial projects.
