Sensys 165° Hinge — Obsidian Black
A wide-angle concealed hinge engineered for full overlay doors where maximum access and a dark, integrated finish are non-negotiable.
Constructed from hardened steel with a durable Obsidian Black powder coat, this Hettich Sensys hinge opens to 165° — significantly beyond the standard 110° — making it the correct choice for corner cabinets, pantry units, and large-format doors where clearance matters. The integrated Sensys soft-close mechanism is factory-set and requires no adjustment. FLASH expanding sockets allow tool-free press-in installation directly into the door bore, reducing fit-out time without sacrificing pull-out resistance.
Product Details
- Material: hardened steel with Obsidian Black powder-coat finish
- Opening angle: 165°
- Overlay type: full overlay
- Mounting: FLASH expanding socket — tool-free press-in, 35mm cup bore
- Soft-close: integrated Sensys mechanism, factory-set
- Weight: 120g per hinge
- SKU: 167.523B | Hettich part no. 9091789
Best For
Corner cabinets, tall pantry units, and large-format doors in dark or monochromatic kitchen schemes where a standard hinge opening angle creates access problems. Suited to cabinetmakers and joiners specifying Blum-pattern bore layouts who require a drop-in Hettich alternative with soft-close included.
