Blum
Blum CLIP top centre hinge for AVENTOS bi-fold lift systems. Unsprung, Boss: EXPANDO 78Z553ET11
$53.34
Like a conductor who gives his personal touch to a composition and so creates a new arrangement of
a masterpiece, you can now enjoy a new feel to the design of living spaces with fittings from the
AVENTOS top family.
Specifications:
● Application: Centre Hinge for AVENTOS Bi-Fold Lift Systems
● Closing Mechanism: Unsprung
● Cover Cap Type: 90M2503
● Cover Cap Type: 70.1503
● Boss Material: Zinc Boss
● Boss Finish: Nickel Plated
● Boss Assembly: EXPANDO
● Flange Width: 57 mm
● Flange Length: 20 mm
● Flange Height: 3 mm
● Diameter Hinge Boss Drilling: 35 mm
● Diameter of Fixing Holes: 8 mm
● Distance Between Drillings: 45 mm
● Excentric Position of Fixing Holes to Hinge Boss Hole: 9.5 mm
● Boss Drilling Depth: 12.6 mm
● Minimum Drilling Distance: 3 mm
● Maximum Drilling Distance: 6 mm
● Arm Material: Steel
● Arm Finish: Nickel Plated
● Collision Measurement (Hinge Arm Height): 21 mm
● Side Adjustment: +/- 2 mm
● Type of Depth Adjustment: Convenient with Spiral Screw
● Depth Adjustment: +1.5/-3 mm
● Hinge Accessories: Mounting Plate 177H3100E, Enclosed
● Hinge Accessories: Furniture Hinge 70T5590BTL, Enclosed
● Item Package: 2 per set (2 CLIP Centre Hinges, 2 CLIP 120° Hinges, 6 MPL)
Specifications:
● Application: Centre Hinge for AVENTOS Bi-Fold Lift Systems
● Closing Mechanism: Unsprung
● Cover Cap Type: 90M2503
● Cover Cap Type: 70.1503
● Boss Material: Zinc Boss
● Boss Finish: Nickel Plated
● Boss Assembly: EXPANDO
● Flange Width: 57 mm
● Flange Length: 20 mm
● Flange Height: 3 mm
● Diameter Hinge Boss Drilling: 35 mm
● Diameter of Fixing Holes: 8 mm
● Distance Between Drillings: 45 mm
● Excentric Position of Fixing Holes to Hinge Boss Hole: 9.5 mm
● Boss Drilling Depth: 12.6 mm
● Minimum Drilling Distance: 3 mm
● Maximum Drilling Distance: 6 mm
● Arm Material: Steel
● Arm Finish: Nickel Plated
● Collision Measurement (Hinge Arm Height): 21 mm
● Side Adjustment: +/- 2 mm
● Type of Depth Adjustment: Convenient with Spiral Screw
● Depth Adjustment: +1.5/-3 mm
● Hinge Accessories: Mounting Plate 177H3100E, Enclosed
● Hinge Accessories: Furniture Hinge 70T5590BTL, Enclosed
● Item Package: 2 per set (2 CLIP Centre Hinges, 2 CLIP 120° Hinges, 6 MPL)
