Blum REVEGO uno + duo Single and Double Door Application with Plinth for Pocket Side Thickness

Elevate your cabinetry with the Blum REVEGO uno + duo pocket system, a sophisticated solution designed for seamless single and double door combinations. This innovative system allows you to completely conceal entire living areas when not in use, providing a clean and minimalist aesthetic for modern interiors. Specifically designed for pocket side thicknesses of 18–19mm, this application with plinth ensures a flush, integrated look across your furniture fronts.

The REVEGO system is engineered for longevity and ease of use, meeting the highest standards of functional performance. Each component is crafted to provide a smooth, intuitive user experience, allowing large doors to glide into the pocket with minimal effort.

Key Features and Specifications

• Certified Durability: Tested and certified for 40,000 opening and closing cycles, ensuring long-term reliability.
• Effortless Operation: The manual operating force is less than 70 N, according to strict durability standards.
• Versatile Design: Suitable for combined applications; it is recommended to design the widest front first to ensure optimal alignment.
• Precision Planning: The internal dimensions of your application (width x height x depth) determine the maximum space available for internal construction.

Installation and Compatibility

To ensure a professional finish and proper functionality, please note the following technical requirements:

• Essential Hardware: Blum System Screws (Counter Sunk Head 6 x 14.5mm, 6611450HG) must be used and are available separately.
• Track and Assembly Sets: Specific track and assembly sets for combined single and double door applications are required to complete the installation.
• Stability Recommendation: We highly recommend using door straighteners (such as CBR04DS or Cinetto models) in conjunction with every REVEGO pocket system to maintain front alignment.
• Machining Requirements: Installation requires a CNC machine or MINIPRESS top with EASYSTICK. Horizontal drillings and a track cut-out are necessary; using the official Blum drilling template for pocket connectors is recommended.

Detailed drilling patterns, cut-to-size dimensions, and comprehensive parts lists can be generated via the Blum Product Configurator. For expert advice on configuring your pocket door system, speak to our KitchenLibrary assistant using the chat function.
