Cinetto B-moved kit for PIANO Coplanar System 1 Door. Track:

The Cinetto PIANO Coplanar System offers ultimate flexibility for modern cabinetry and wardrobe design. Featuring a sophisticated mechanism that incorporates all essential movements, the track can be cut to size to meet specific project requirements. This system allows for the creation of seamless combinations with one, two, or three doors, ensuring a completely flush, high-end look when the unit is closed. Highly adaptable, the PIANO System allows users to modify the gap between the doors and the floor (17mm, 25mm, or 35mm) by simply adjusting a single component of the lower slide. It is designed for smooth operation, featuring integrated soft-opening and soft-closing technology for a premium feel.

Features:

• Aligned wardrobe panels providing a completely flush look when closed
• Soft-opening and soft-closing functionality
• Compatible with both wooden doors and aluminium-framed doors
• Supports configurations of up to 3 doors
• Fully compatible with B-moved automated systems
• Handle profiles available for a finished aesthetic

Specifications:

• Track Lengths: Available in 2m and 4m
• Maximum Door Height: 3000mm
• Door Thickness: Minimum 16mm, Maximum 43mm (55mm including handles)
• Door Height Adjustment: ±6mm
• 2-Door Weight Capacity: Max 60kg per door
• 3-Door Weight Capacity: Max 45kg for outer doors, 100kg for middle doors
• Door Width (2-door systems): Min 890mm, Max 1800mm
• Door Width (3-door systems): Min 1300mm, Max 1800mm

Note: This kit provides the necessary components to transition your sliding system into a high-performance B-moved application. Simply incorporate these components into your existing setup to enjoy automated movement.
