KitchenLibrary
100 Hinge — 110° Full Overlay
$2.40
A precision-engineered concealed hinge built for full overlay cabinetry with a clean, flush-mounted result.
Hinge plate required. This hinge needs a compatible mounting plate to be installed. Plates are sold separately — please add the correct plate to your order.
Constructed from nickel-plated steel, this hinge delivers consistent, smooth movement across its full 110° arc. The nickel finish resists tarnishing and integrates discreetly into contemporary cabinet interiors. Available in screw-on and knock-in cup patterns to suit different carcass materials and installation preferences.
Product Details
- Material: Nickel-plated steel
- Finish: Nickel plated
- Opening angle: 110°
- Overlay type: Full overlay
- Cup options: Screw-on Ø35mm, Knock-in Salice pattern, Knock-in Hettich pattern
- Weight: 80g per hinge
Best For
Suited to full overlay kitchen, bathroom, and wardrobe cabinetry where a concealed hinge is required. The 110° opening angle provides unobstructed access to cabinet interiors — practical for deep base cabinets and pantry units. Compatible with standard 35mm cup boring.
