Soft-Close Hinge — 110° Full Overlay

A full overlay soft-close hinge engineered for silent, precise door movement in contemporary cabinetry.

Constructed with an integrated soft-close mechanism, this hinge delivers controlled, noiseless closing action across kitchen, laundry, and wardrobe applications. The 110° opening angle provides full door clearance, while the precision-moulded cup ensures a secure, rattle-free fit. Available in screw-on and knock-in cup patterns to suit a range of cabinet carcass types.

Product Details

• Material: Steel with polymer components
• Finish: Standard (uncoated steel)
• Opening angle: 110°
• Overlay type: Full overlay
• Cup options: Screw-on Ø35mm, Knock-in Salice pattern, Knock-in Hettich pattern
• Integrated soft-close mechanism; compatible with standard KitchenLibrary mounting plates

Best For

Suited to kitchen and joinery projects where silent door operation is a specification requirement. Works across frameless cabinet construction with standard 35mm cup boring. The knock-in variants are particularly well-suited to high-volume cabinet production where press-fit installation speeds up assembly.
