Pull Handle Size Guide: Length and Spacing Done Right

The short answer

For most kitchens, a pull handle should be roughly one-third the width of the drawer front or one-third the height of the door it sits on. That is the working principle behind this pull handle size guide: a 900mm drawer wants a handle around 300mm overall, a 600mm drawer around 200mm, and a tall pantry door usually takes a 320mm or larger pull.

That is a starting point, not a law. Proportion is a judgement, and the numbers below give you the range that reads as considered rather than accidental.

The one figure you must get exactly right is not length — it is centre-to-centre spacing, the distance between the fixing holes. Get that wrong and the handle either will not fit the holes you drilled, or it fits and looks wrong.

Centre-to-centre versus overall length

Every bar and D-pull has two measurements, and they are not the same thing.

Centre-to-centre (CTC) is the distance between the two mounting screws. This is the measurement that decides where you drill and whether a replacement handle will fit an existing hole pattern.

Overall length is the full end-to-end dimension of the handle, including the returns (the legs that stand it off the door).

A handle with a 160mm CTC might have an overall length of 180mm or 200mm depending on how long its returns are. When you are matching a look, you care about overall length. When you are drilling, you care about CTC. Mix the two up and you will order the wrong part.

Most cabinet handles follow a 32mm module, so CTC sizes step in familiar increments: 96, 128, 160, 192, 224, 256, 288 and 320mm, then jumping to appliance-scale pulls at 448, 512, 640 and beyond. Not every range holds to the 32mm grid, so always read the spec rather than assume.

Sizing handles for drawers

Drawers are the easy case because the handle usually sits horizontally, centred on the front.

Use the one-third guideline on width, then round to the nearest available size.

• A 300mm bank drawer suits a 96–128mm CTC handle.
• A 450mm drawer suits 128–160mm.
• A 600mm drawer suits 160–192mm.
• A 900mm drawer suits 256–320mm, or two smaller handles spaced symmetrically.

On wide drawers — 900mm and up — a single central handle can feel undersized, and a long handle can flex or rack if it is only fixed at two points close together. Two handles, each placed about a quarter of the way in from either end, spreads the pull load and looks balanced. It also means both hands do the same work, which matters on a heavy pot drawer.

A slim bar pull like the Flapp Pull Handle comes in a run of CTC sizes, so you can hold the one-third proportion across a whole run of different drawer widths without changing the handle family. Keeping the profile consistent and letting only the length change is what makes a kitchen read as designed rather than assembled from a bin.

Sizing handles for doors

Doors are where proportion matters most, because a vertical handle on a tall door has more room to look wrong.

On a standard base or overhead door, mount the handle vertically and size it to roughly one-third the door height, within reason. A 720mm overhead door reads well with a 160–224mm handle. A full-height pantry or larder door — often 2,000mm or more — carries a 320mm, 448mm or even taller pull comfortably, and a small handle on a big door looks mean.

Placement is the other half of the job.

• On base cabinet doors, mount the handle vertically at the top corner, with the top screw roughly 50–75mm down from the top edge.
• On overhead doors, mount vertically at the bottom corner, the same distance up from the bottom edge, so it falls to hand.

The logic is simply where your hand naturally reaches: down for a wall cabinet, up for a base cabinet.

Lip and edge pulls — when length rules change

Not every handle follows the one-third guideline, because not every handle is a bar.

Lip pulls (also called edge or profile pulls) hook over or mount to the edge of the door or drawer. Here the visual weight is different — the handle reads as a fine line along the edge rather than a bar on the face — so you can run a longer lip pull without it dominating, and many people fit one that spans most of the drawer width.

The Vann Lip Pull is a good example of the type — quiet from the front, generous to the hand. Lip pulls suit a flat, contemporary look and keep the door face clean, which is why they turn up so often on handleless-style kitchens that still want something to grip.

The trade-off is honest: an edge-mounted pull projects less, so it is less comfortable for a heavy drawer full of crockery than a full bar you can hook four fingers through. If a drawer is going to carry real weight, a substantial D-pull earns its place.

A quick reference table

Comparable rows only — overall length is a typical figure and varies by handle profile, so confirm against the spec before drilling.

| Cabinet front | Front width / height | Suggested CTC | Typical overall length | | --- | --- | --- | --- | | Bank drawer | 300mm | 96–128mm | ~110–150mm | | Standard drawer | 450mm | 128–160mm | ~150–180mm | | Wide drawer | 600mm | 160–192mm | ~180–210mm | | Pot drawer | 900mm | 256–320mm (or two handles) | ~280–340mm | | Overhead door | 720mm high | 160–224mm | ~180–245mm | | Pantry door | 2,000mm+ high | 320–448mm+ | ~340–470mm |

What to check before you buy

A few things catch people out, and all of them are cheaper to fix before you drill than after.

Confirm CTC against your holes. If you are replacing handles, measure the existing hole spacing before ordering. A 160mm CTC handle will not cover holes drilled at 128mm, and filling and re-drilling a finished door is a bad afternoon.

Check the return depth. The return is the standoff between the door face and the grip. Around 32–38mm is comfortable for most hands; less than that and thick fingers catch on the door. If anyone in the house has larger hands or reduced grip, size the return up.

Match the fixing screw to the door thickness. Handles ship with standard machine screws, usually M4. A thicker door — a shaker front, or a door with an applied moulding — may need longer screws than the ones in the box. Confirm before install day.

Buy one first if you are unsure. A single handle held against a sample door tells you more about proportion than any measurement. It is the cheapest insurance in the job.

For smaller drawers and lighter doors, a compact lip pull such as the Ona Lip Pull keeps the proportion right without over-handling a small front — the same one-third thinking, applied to a smaller module.

What installers get wrong

Three mistakes account for most of the handles that look slightly off.

The first is inconsistent placement — measuring from the top on one door and the bottom on another, so the handles sit at different heights across a run. Use a drilling jig and set it once.

The second is ignoring proportion on a mixed run — fitting the same 160mm handle on every drawer regardless of width, so a 300mm drawer looks over-handled and a 900mm one looks starved. Scale the length to the front.

The third is treating CTC and overall length as interchangeable when ordering. They are not, and the spec sheet always states both.
